Haul it all with the Abound, Aventons first ever cargo ebike! Its versatility and step-through frame puts the you in you-tility. Rack it, stack it, and load the kiddos, too!

Equipped with a torque sensor and powerful 750W rear hub motor, getting around with everything you need in tow has never been easier. Let Abound do most of the heavy lifting by switching between the four new pedal assist levels: eco, tour, sport, and turbo. The all-new turn signal functionality alerts others that youre making moves, while the front headlight sheds light on the road ahead. With Abound, the possibilities are boundless.

Backlit LCD Display

The Full Color Display provides all the important data you need, including speed, distance traveled, pedal assist level, and much more. Activate your ebikes integrated lights and sync to the Aventon app to share your rides with friends and a larger Aventon community.

Torque Sensor

The torque sensor recognizes your pedaling output and matches it, amplifying your momentum. This provides a more natural riding experience, conserves battery life, and extends riding range.

Front Suspension

A suspension fork with up to 50mm of travel provides comfort for you and your precious cargo.

Fenders & Rear Rack

Front and rear fenders will keep you protected from the elements, while the rear rack, with up to 143 lb weight capacity, offers more room to bring everything you need, wherever you want to go.

Dropper Seatpost

Abounds new quick-adjusting dropper seatpost is comfort on command. By squeezing the lever beneath the seat, you can easily glide the seat up or down, giving you ultimate control and comfort over your riding position.

Storage Bag

The storage bag lets you zip up and stash away the personal items you might need to bring along for the long haul around town.

Footboards

Footboards will let you rest assured that your passenger has a place to rest their legs and ride comfortably out of harms way.

Integrated Lights w/ Turn Signal Functionality

Integrated front and rear lights allow you to see and be seen on the road, while the all-new turn signal functionality will indicate your next move to motorist and other cyclists.

Specifications

The Abound ships as a Class II ebike, with pedal assist and throttle. The Abound will also operate with the throttle unplugged and removed, should you want to ride in an area where throttles are prohibited. Aventon ebikes are built to the IPX4 water-resistant standard. IPX4 means that your bike is resistant to water splashes from any direction. This means its OK to ride your ebike in light rain. It wont be harmed by spray from a wet road or raindrops. Your ebike is not intended to be exposed to prolonged rain or submerged or subjected to a pressurized spray. Dont use a pressure washer or sprayer to clean your ebike. *Using PAS 1 throughout flat terrain with a rider weight of 160 lb.

MOTOR 750W (Sustained), 48V Brushless Rear Hub Motor

THROTTLE Throttle on demand – Throttle from a complete stop DISPLAY LCD Smart Easy Read Display with Backlight, Colorful screen with app SPEED Up to 20 MPH on Pedal Assist BATTERY Removable Internal Lithium-ion 48V, 15Ah (720Wh) SENSORS Torque Sensor PEDAL ASSIST 4 Levels CHARGER 48V 3 Amp Fast Charger, 4-5 Hour Charging RANGE Up to 50 Miles* on PAS 22 Miles on Throttle FRAME 6061 Single-Butted Aluminum Alloy with Internal Battery WEIGHT 81 lbs PEDALS 9/16′ Alloy Platform FORK Suspension Fork with 50mm travel, with lockout TOTAL WEIGHT LIMIT 440 lbs REAR RACK WEIGHT LIMIT 143 lbs CENTER STAND Included, Center Mount BOTTOM BRACKET Square Taper, Sealed, Torque Sensor CRANKSET 170mm w/ 52 T REAR DERAILLEUR 7 Speed CASSETTE 14-28T, 7 Speed SHIFT LEVER 7 Speed Twist BRAKES Hydraulic Disc Brakes CHAIN 148 Link, 7 Speed RIM Double Wall Aluminum 36h Front & Rear SPOKES Black Stainless 13G Front / 12G Rear TUBES Butyl Rubber, Schrader Valve HUBS 36H Disc Nutted Front, Nutted Rear TIRES 20″ x 2.4″ Puncture Resistant, Reflective Sidewalls SADDLE Aventon Saddle SEATPOST Dropper Seatpost, 30.9mm x 440mm STEM Folding, Height Adjustable, 31.8mm, 9 Degree Rise SEAT CLAMP 34.9 mm Quick Release HANDLEBARS Aluminum 31.8mm, 700mm HEADSET Sealed Bearing Headset GRIPS Ergonomic Comfort FOOTBOARDS Aluminum STORAGE BAG Polyester, EVA Waterproof DIMENSIONS Bike Box: 167 cm x 37 cm x 73 cm Built Bike: 1910 mm (l) x 1125 mm (h) Rear Rack: 28 in (l) x 6.75 in (w)

Geometry

Frame Size

One size fits all

Top Tube Length

613mm

Reach

426mm

Head Tube Length

174mm

Standover Height

472mm

Wheelbase

1274mm
